GB37 Grade 8.8 T-Head Bolts for Machine Tool Clamping

PRODUCT SPECIFICATIONS

GB37 Grade 8.8 T-Head Bolts for Machine Tool Clamping

Grade8.8 T-head bolts identified as GB37 in the supplier title, for die plates, presses, milling machines and T-slot clamping. Original M12-M24 diameters and lengths remain in order. Source detail identifies45# carbon steel and blackened finish; the diagram and table preserve head and shank dimensions.

Price range: $0.22 through $2.46

Reference unit price · Confirm quantity and terms by inquiry

No online payment. Only email is required to inquire.

Product details

GB37 Grade 8.8 T-Head Bolts for Machine Tool Clamping - Technical Dimensions

Grade8.8 T-head bolts identified as GB37 in the supplier title, for die plates, presses, milling machines and T-slot clamping. Original M12-M24 diameters and lengths remain in order. Source detail identifies45# carbon steel and blackened finish; the diagram and table preserve head and shank dimensions.

Technical Specifications

Property Supplier data
Supplier standard GB37
Supplier grade 8.8
Source material 45# carbon steel
Finish Blackened
Type T-head clamping bolt
Reference unit mm

Model: 692561002116

View all specifications (92 options)
SpecificationUnit priceItem Ref
12*40USD 0.44692561002116
12*50USD 0.46692561002116
12*60USD 0.22692561002116
12*70USD 0.25692561002116
12*80USD 0.27692561002116
12*90USD 0.29692561002116
12*100USD 0.31692561002116
12*110USD 0.33692561002116
12*120USD 0.35692561002116
12*130USD 0.37692561002116
12*140USD 0.39692561002116
14*60USD 0.30692561002116
14*70USD 0.34692561002116
14*80USD 0.37692561002116
14*90USD 0.39692561002116
14*100USD 0.42692561002116
14*110USD 0.45692561002116
14*120USD 0.48692561002116
14*130USD 0.51692561002116
14*140USD 0.53692561002116
14*150USD 0.56692561002116
14*160USD 0.59692561002116
14*170USD 0.62692561002116
14*180USD 0.65692561002116
14*200USD 0.70692561002116
14*220USD 0.76692561002116
16*60USD 0.39692561002116
16*70USD 0.43692561002116
16*80USD 0.46692561002116
16*90USD 0.49692561002116
16*100USD 0.53692561002116
16*110USD 0.56692561002116
16*120USD 0.59692561002116
16*130USD 0.63692561002116
16*140USD 0.66692561002116
16*150USD 0.69692561002116
16*160USD 0.72692561002116
16*170USD 0.76692561002116
16*180USD 0.79692561002116
16*200USD 0.85692561002116
16*220USD 0.91692561002116
16*250USD 1.02692561002116
16*280USD 1.11692561002116
16*300USD 1.18692561002116
18*60USD 0.49692561002116
18*70USD 0.54692561002116
18*80USD 0.58692561002116
18*90USD 0.63692561002116
18*100USD 0.66692561002116
18*110USD 0.71692561002116
18*120USD 0.75692561002116
18*130USD 0.79692561002116
18*140USD 0.83692561002116
18*150USD 0.87692561002116
18*160USD 0.91692561002116
18*170USD 0.95692561002116
18*180USD 1.00692561002116
18*190USD 1.02692561002116
18*200USD 1.07692561002116
18*220USD 1.15692561002116
18*230USD 1.22692561002116
18*250USD 1.27692561002116
18*280USD 1.40692561002116
20*60USD 0.61692561002116
20*70USD 0.68692561002116
20*80USD 0.73692561002116
20*90USD 0.78692561002116
20*100USD 0.83692561002116
20*110USD 0.89692561002116
20*120USD 0.94692561002116
20*130USD 0.99692561002116
20*140USD 1.04692561002116
20*150USD 1.09692561002116
20*160USD 1.14692561002116
20*170USD 1.19692561002116
20*180USD 1.25692561002116
20*200USD 1.36692561002116
20*220USD 1.44692561002116
20*250USD 1.59692561002116
20*300USD 1.86692561002116
24*100USD 1.35692561002116
24*110USD 1.42692561002116
24*120USD 1.50692561002116
24*130USD 1.58692561002116
24*140USD 1.64692561002116
24*150USD 1.72692561002116
24*160USD 1.79692561002116
24*170USD 1.87692561002116
24*180USD 1.94692561002116
24*200USD 2.08692561002116
24*220USD 2.24692561002116
24*250USD 2.46692561002116
